The UOLP Handheld 3.39 Series is a microprocessor-based instrument that provides continuous monitoring and detection of ultrasonic frequency (in kHz) and reference energy (in mVrms - voltage root mean sqaure) in a liquid medium of a ultrasonic cleaning bath. It employed a handheld probe made of 316 L stainless steel to collect data at random points. With the reliable data collected, one can made a good judgment of performance of the ultrasonic tank over a period of time.

Tank Mapping or Profiling
The probe can be made to move along the tank surface to carryout tank mapping. With the tank being mapped, hot or cold spots problem could be easily identified. This may also help to provide information of mechanical problem like weak transducer bonding or even area of low energy level.

User friendliness
NO maintenance is required for the probe or the controller at any one time.

Cost Effectiveness
The low cost yet reliable UOL CF Series offers a total process control of an ultrasonic cleaning system that has never done before.
An essential tool for all engineers to understand ultrasonic.

Packaging

1. Packaging Box with custom packing space
2. Ultrasonic handheld series (CF/LF)
3. 316L 400mm Stainless steel probe
4. +9VDC Power adapter
5. Operating manual (hardcopy)
